- Size: 70m³
- Place of Origin: Jinan,Shandong,China
- Brand Name: MHM
- Model Number: JM36-1000/1
- Weight: 240000.000 kg
Unit JM36-1000/1 Nominal pressure KN 10000 Nominal working stroke mm 13 Slide stroke mm 600 Number of slide stroke c.p.m succession:10-20 once:9 Max shut height mm 1500 Shut height adjustment mm 600 Micro-inching stroke adjustment c.p.m 3-6 Effective bolster size(FB×LR) mm 2000×5000 Slide bottom effctive size(FB×LR) mm 2000×5000 Type pf moving bolster antedisplacement Air cushion Air cushion pressure KN 2000 Number of cylinders Pieces 2/1 Stroke mm 250 Air pressure MPa 0.55 Form rigidity Main motor power Kw Electrical control form PLC Height above floor mm <11000 Total weight Kg 240000
- JM36 series Straight-sided two-point single action mechanical press adopt founded and welded combined construction,the base,left and right uprights and crossbeam connected through four tightening bolts,connection between the cross beam and slide adopts guide pillar and guide pillar bush structure.
- Clutch-brake of the presses adopt floating disk friction and low inertia construction,controlled by safe double valve, reliable performance,high concatenation and long life.
- In the slide,there is imported hydraulic overload protecting device,which can protect machine run normally and safely.
- Centralized lubricating system of thin oil.
- Electrical lubricating system adopts imported touch screen and PLC control.
- Locking adjusting device of cushion and photoelectric protector can be chosen,if you need.
