Product Details
- Size: 50m³
- Place of Origin: Jinan,Shandong,China
- Brand Name: MHM
- Model Number: JS2-250A
- Weight: 52000.000 kg
| Unit | JS2-250A | ||
| Nominal pressure | KN | 2500 | |
| Nominal working stroke | mm | 13 | |
| Slide stroke | mm | 350 | |
| Number of slide stroke | c.p.m | 25 | |
| Max shut height | mm | 700 | |
| Shut height adjustment | mm | 300 | |
| Micro-inching stroke adjustment | c.p.m | 3-6 | |
| Effective bolster size(FB×LR) | mm | 1250×2770 | |
| Slide bottom effctive size(FB×LR) | mm | 1250×2560 | |
| Type pf moving bolster | |||
| Air cushion | Air cushion pressure | KN | 400 |
| Number of cylinders | Pieces | 2/1 | |
| Stroke | mm | 150 | |
| Air pressure | MPa | 0.55 | |
| Form | rigidity | ||
| Main motor power | Kw | 37 | |
| Electrical control form | PLC | ||
| Height above floor | mm | 5890 | |
| Total weight | Kg | 52000 | |
- JM36 series Straight-sided two-point single action mechanical press adopt founded and welded combined construction,the base,left and right uprights and crossbeam connected through four tightening bolts,connection between the cross beam and slide adopts guide pillar and guide pillar bush structure.
- Clutch-brake of the presses adopt floating disk friction and low inertia construction,controlled by safe double valve, reliable performance,high concatenation and long life.
- In the slide,there is imported hydraulic overload protecting device,which can protect machine run normally and safely.
- Centralized lubricating system of thin oil.
- Electrical lubricating system adopts imported touch screen and PLC control.
- Locking adjusting device of cushion and photoelectric protector can be chosen,if you need.
