Straight-sided one-point action mechanical press

Straight-sided one-point action mechanical press

  • Min.Order Quantity: 1 Set
  • Supply Ability: 5 Sets per Year
  • Port: China port
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:2007-09-07
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Size:  50m³
  • Place of Origin:  Jinan,Shandong,China
  • Brand Name:  MHM
  • Model Number:  JM31-400
  • Weight: 48500.000 kg



Unit JM31-400
Nominal pressure KN 4000
Nominal working stroke mm 13
Slide stroke mm 400
Number of slide stroke c.p.m 16
Max shut height mm
Shut height adjustment mm
Micro-inching stroke adjustment c.p.m 3-5
Effective bolster size(FB×LR) mm 1200×1240
Slide bottom effctive size(FB×LR) mm 1000×1230
Air cushion Force KN 500/76
Quantities Pieces Single crown
Stroke mm 200
Air pressure MPa 0.55
Slide Knockout rod Form rigidity
Stroke mm 150
Main motor power Kw 45
Electrical control form PLC
Height above floor mm 6130
Total weight Kg 48500


This press is general-purposed straight sided one point mechanical presses,which can complete the cold stamping process,such as punching,bending,forming,shallow tensile,calibration and so on.When it is working,its punching force is less than 60% of the nominal pressure.

General requirements;

1.The general layout of the press:The press mainly consists of machine frame,main drive of the crossbeam,clutch,break,die block,air pipeline,tank,air cushion,ladders,railings,walking board,electrical control system and other components.The overall layout is compact and elegant.

2. The structure features: The base,columns,crossbeams and die block are steel plate welded structure ;the base and the column,the column and the crossbeam are positioned by the square button.The main drive of crossbeam is beautiful,with good bearing force,stable accuracy and low noise.

3.The press adopts dry clutch,brakes,with compact structure and easy maintenance.It adopts ROSS double valve control.

4.The press should adopt dilute oil automatic circulation lubrication and disperse lubrication to fully guarantee the reliable operation of the press and to improve the service life of friction pair.

5.It has hydraulic overload protection device to avoid equipment accidents,such as damage caused by overloading.
