Product Details
- Size: 60m³
- Place of Origin: Jinan,Shandong,China
- Brand Name: MHM
- Model Number: JM39-1000
- Weight: 296700.000 kg
| Unit | JM39-1000 | ||
| Nominal pressure | KN | 10000 | |
| Nominal working stroke | mm | 13 | |
| Slide stroke | mm | 800 | |
| Number of slide stroke | c.p.m | succession:10-18 once：10 | |
| Max shut height | mm | 1500 | |
| Shut height adjustment | mm | 600 | |
| Micro-inching stroke adjustment | c.p.m | 3-6 | |
| Effective bolster size(FB×LR) | mm | 2500×5000 | |
| Slide bottom effctive size(FB×LR) | mm | 2500×5000 | |
| Type pf moving bolster | antedisplacement | ||
| Air cushion | Air cushion pressure | KN | |
| Number of cylinders | Pieces | ||
| Stroke | mm | ||
| Air pressure | MPa | 0.55 | |
| Form | rigidity | ||
| Main motor power | Kw | 112 | |
| Electrical control form | PLC | ||
| Height above floor | mm | 9250 | |
| Total weight | Kg | 296700 | |
