Product Details
- Size: 60m³
- Place of Origin: Jinan,Shandong,China
- Brand Name: MHM
- Model Number: JM39-800
- Weight: 320000.000 kg
| Unit | JM39-800 | ||
| Nominal pressure | KN | 8000 | |
| Nominal working stroke | mm | 13 | |
| Slide stroke | mm | 1000 | |
| Number of slide stroke | c.p.m | succession:8-16 once：8-12 | |
| Max shut height | mm | 1400 | |
| Shut height adjustment | mm | 700 | |
| Micro-inching stroke adjustment | c.p.m | 3-5 | |
| Effective bolster size(FB×LR) | mm | 2000×4000 | |
| Slide bottom effctive size(FB×LR) | mm | 2000×4000 | |
| Type pf moving bolster | |||
| Air cushion | Air cushion pressure | KN | 1200 |
| Number of cylinders | Pieces | 2/1 | |
| Stroke | mm | 0-300 | |
| Air pressure | MPa | ≥0.55 | |
| Form | rigidity | ||
| Main motor power | Kw | 110 | |
| Electrical control form | PLC | ||
| Height above floor | mm | 9835 | |
| Total weight | Kg | 320000 | |
