Product Details
- Size: 60m³
- Place of Origin: Jinan,Shandong,China
- Brand Name: MHM
- Model Number: LS4-1600
- Weight: 400000.000 kg
| Unit | LS4-1600 | ||
| Nominal pressure | KN | 16000 | |
| Nominal working stroke | mm | 13 | |
| Slide stroke | mm | 1000 | |
| Number of slide stroke | c.p.m | succession:7-18 once：13 | |
| Max shut height | mm | 1500 | |
| Shut height adjustment | mm | 400 | |
| Micro-inching stroke adjustment | c.p.m | 3-6 | |
| Effective bolster size(FB×LR) | mm | 2200×4200 | |
| Slide bottom effctive size(FB×LR) | mm | 2200×4200 | |
| Air cushion | Air cushion pressure | KN | 3500 |
| Number of cylinders | Pieces | 2/1 | |
| Stroke | mm | 0-300 | |
| Air pressure | MPa | ≥0.55 | |
| Main motor power | Kw | 280 | |
| Electrical control form | PLC | ||
| Height above floor | mm | ＜12000 | |
| Total weight | Kg | - | |
