CNC floor boring and milling machine

CNC floor boring and milling machine

  • Min.Order Quantity: 1 Set
  • Supply Ability: 5 Sets per Year
  • Port: China port
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
Verified Supplier JINAN METALIST TECH GROUP CO.LTD
| Factory
Experience:2007-09-07
Visit Factory
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Size:  50m³
  • Place of Origin:  Jinan,Shandong,China
  • Brand Name:  MHM
  • Model Number:  TK6920
  • Weight: 113000.000 kg
Unit TK6920
Boring bar diameter mm 200
Milling shaft diameter mm 335
Spindle taper ISO NO.60
Ram-sectional dimension mm 500×540
Boring bar length mm 1200
Ram-sectional length mm 1200
Total travel length mm 2400
Main motor power kw 45
Spindle speed range rpm 4-440
Feed range mm/min 0-1300
Speed mm/min 1200
X-axis stroke length mm 10000
Y-axis stroke length mm
Feed range mm/min 1-4000
Speed mm/min 4000
Main axis to the ground plane table distance mm 560-4560
Main motor power Kj 78
Total weight Kg 113000
  • Size:  50m³
  • Place of Origin:  Jinan,Shandong,China
  • Brand Name:  MHM
  • Model Number:  TK6920
  • Weight: 113000.000 kg
