Product Details
- Size: 50m³
- Place of Origin: Jinan,Shandong,China
- Brand Name: MHM
- Model Number: TK6913
- Weight: 58000.000 kg
| Unit | TK6913 | ||
| Boring bar diameter | mm | 130 | |
| Milling shaft diameter | mm | 221.44 | |
| Spindle taper | |||
| Ram-sectional dimension | mm | 380×380 | |
| Boring bar length | mm | 800 | |
| Ram-sectional length | mm | 600 | |
| Total travel length | mm | 1400 | |
| Main motor power | kw | 22 | |
| Spindle speed range | rpm | 4-420 | |
| Feed range | mm/min | 10-800 | |
| Speed | mm/min | 800 | |
| X-axis stroke length | mm | 6000 | |
| Y-axis stroke length | mm | 3000 | |
| Feed range | mm/min | 1-3000 | |
| Speed | mm/min | 3000 | |
| Main axis to the ground plane table distance | mm | 480-3480 | |
| Main motor power | Kj | 54.6 | |
| Total weight | Kg | 58000 | |
